Preliminary: The AMP-FL8621-OB-19 is O-band bismuth-doped fiber amplifier producing ≥ +19 dBm output power. It offer a very broadband and flat gain across the O-band, making it very suitable for ultra-wideband WDM transmission.
Product Type : Bench Top
Operating Wavelength：1260 nm ~1340 nm
| Product Number | Operating WaveLength (nm) | Nominal WL (nm) | Output Power (dBm) (*1) | Gain (dB) (*2) | Gain Flatness (dB) | NF (dB) (*2) | PER (dB) | IN/OUT Fiber | Standard Connector | IN/OUT Isolator | Std. Dimension (H x W x D, mm) (*3) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AMP-FL8621-OB-19 | 1260 to 1340 | 1310 | ≥ +19 | ≥ 20 | N/A | ≤ 7 | N/A | SMF (*4) | FC/PC | Built In | 88 x 430 x 350 |
(*1) Input Power: 0 dBm @ Nominal Wavelength
(*2) Input Power: -30 dBm @ Nominal Wavelength
(*3) Does not include protrusions
(*4) G.652 compliant (e.g. SMF28)
| Attribute | Specification |
|---|---|
| Control Mode | ACC (Auto Current Control) and ALC (Auto Light Control) |
| Monitor & Alarm | Input power / Output power / Pump LD current / Pump LD temperature / Case temperature |
| Safety Function | Remote Interlock / Interlock with input Alarm |
| Remote Interface | RS-232C / IEEE488.1 (GP-IB) |
| Temperature | Operation : 0 to 40 ºC / Storage : -10 to 60 ºC |
| Power Supply | AC 100 to 240 V (50/60 Hz) |
| Number | Option |
|---|---|
| -012 | FC/APC Connector |
| -014 | SC/APC Connector |
| -093 | Reflection Monitor and Interlock |
| -123 | Rack-mount kit Size: 88(H)x440(W)x350(D) mm |
